The EMERGENCY UNLOADING DEVICE is mainly used for the timely transfer of oil product inside the ship in case of maritime accident. It can reduce oil overflow and prevent oil pollution rapidly and effectively, protecting the ecological environment. The equipment is widely used in marine harbors, port terminals, shipyards and other occasions where ship oil spills and needs to be unloaded.
It consists of the storage and transportation platform, unloading pump, explosion-proof motor type (explosion-proof diesel model), hydraulic power station, pipe reel, oil hose, hydraulic hose, spare parts and maintenance toolbox.
Item | Parameter | |||||
Model | XZB-20F | XZB-50F | XZB-80F | XZB-100F | XZB-200F | XZB-300F |
Max. Oil Transportation Rate，T/h | 20 | 50 | 80 | 100 | 200 | 300 |
Power，KW (Explosion-proof Motor) | 18.5 | 30 | 30.0 | 45.0 | 55.0 | 75.0 |
Power，KW (Explosion-proof Diesel) | 22 | 22 | 22 | 40 | 40 | 40 |
Working Pressure of the Hydraulic Motor，MPa | 4~10 | 5~12 | 6~14 | 6~14 | 8~14 | 10~16 |
Allowable Working Temperature of the Hydraulic Oil，℃ | 60 | |||||
Lift of Pump，m | ≥30 | |||||
Tubing Size | 3” | 4” | 5” | 6” | 6” | 8” |
Pump Head Weight，kg | 120 | 140 | 150 | 250 | 250 | 350 |
Hydraulic Power Station Weight，kg | 1000 | 1000 | 1000 | 1150 | 1150 | 1150 |
