OIL TRAWL

OIL TRAWLDownload Catalog

As for crude oils of high viscosity, which are condensed into solid blocks at room temperature, floating or shifting in waters, and are difficult to be retrieved by a mechanical recovery device. A better recovery can be made with the oil trawl. The oil trawl is mainly composed of a frame, buoy, main net, dragnet and nylon fabric bag. The dragnet is detachable from the main net. When the net is full, it can be replaced with a new one.

Technical?Specification

        Model







Parameter

SW-2

SW-3

SW-4

SW-5

SW-10

Frame Size(mm)

2150×650×1080

2150×650×1080

2150×650×1080

2150×650×1080

2150×650×1080

Net Bag Volume(m3)

2

3

4

5

10

Mesh Size

5×5 or 10×10

Towing Speed (Kn)

0.5～1

0.5～1

0.5～1

0.5～1

0.5～1

Package Box Size (mm)

2280×1230×870

2280×1230×870

2280×1230×870

2280×1230×870

2280×1230×870



Boom Arm



10.5m

(It can be configured according to the user’s needs. )

Containment Boom

for Trailing

Type 1000*10m, 2 pieces

(It can be configured according to the user’s needs.)


Note: The technical data are subject to change without notice due to modifications to the product and shall be confirmed by the manufacturer and customer.
