QUICK DEPLOYMENT OIL BOOM
QUICK DEPLOYMENT OIL BOOM
QUICK DEPLOYMENT OIL BOOM
QUICK DEPLOYMENT OIL BOOM
QUICK DEPLOYMENT OIL BOOM

QUICK DEPLOYMENT OIL BOOMDownload Catalog

The QUICK DEPLOYMENT OIL BOOM is used to control oil spill in sea or port environment. It is usually wound on the reel, and it can be deployed into the water without air inflation. It is equipped with corresponding oil boom reel frame (container) and oil boom power station.

FEATURES OF QUICK DEPLOYMENT OIL BOOM:

It is made of double-sided high-strength flexible material, having high resistance to oil and sunlight and long service life. Rubber material can be used in harsh environment.

It can be used for oil spill containment and prevention of oil spill diffusion in marine or port water environment, with fast deployment performance.

Only two operators are needed and the recover method is mechanical.

More +

Technical?Specification

Model

Parameter

KW600

KW800

KW900

KW1000

(KW1100)

KW1200

KW1400

(KW1600)

Overall Height  mm

600

800

900

1000

(1100)

1200

1400

(1600)

Water Level(mm)

150

280

320

340

(390)

380

480
(530)

Underwater Depth mm

350

420

490

540

(590)

650

790

(840)

Length per Section  m

200

200

200

200

200

200

Tensile Strength KN

30

50

55

65

70

80

Deployment Speed m/min

≥40

≥40

≥40

≥40

≥40

≥40

Max. Resistance to Wave Height (m)

0.5

0.8

1.2

1.5

1.8

2.0

Max. Resistance to Wind Speed (m/s)

5

6

8

10

12

15

Max. Resistance to Current Speed(Kn)

0.5

0.8

1.2

1.5

1.5

2.0


Note: The technical data are subject to change without notice due to modifications to the product and shall be confirmed by the manufacturer and customer.
