SOLID FLOAT PVC OIL BOOM is a kind of economical and universal oil boom, which is used to intercept oil spills and other floating objects on the water surface. It is suitable for long-term fixed cloth on the water surface. Because of its rapid release and easy operation, it has been widely used in rivers, harbors, lakes, offshore oil platforms and other waters.
It is made of high strength cloth coated with orange PVC on both sides and has good oil resistance and aging resistance.
The solid float has large buoyancy reserve, good wave riding performance and stability.
The boom body is equipped with pull rope, reinforcing belt (steel wire rope) and ballast chain as load-bearing components, which has high tensile performance.
|
Model
Parameter |
WGS600 |
WGS750 |
WGS800 |
WGS900 |
WGS1000 |
WGS1100 (WGS1200) |
WGS1500 |
|
Overall Height(mm) |
600 |
750 |
800 |
900 |
1000 |
1100 (1200) |
1500 |
|
Freeboard (mm) |
150 |
210 |
280 |
320 |
340 |
370 (420) |
520 |
|
Draft (mm) |
380 |
390 |
420 |
490 |
540 |
560 (610) |
760 |
|
Length per Section(m) |
10/20 |
||||||
|
Max. Working Tensile Strength (KN) |
20 |
25 |
25 |
25 |
45 |
45 |
50 |
|
Max. Resistance to Wave Height (m) |
0.5 |
0.5 |
1.5 |
1.8 |
2 |
2 |
3 |
|
Max. Resistance to Wind Speed (m/s) |
8 |
10 |
15 |
15 |
18 |
20 |
20 |
|
Max. Resistance to Current Speed (Kn) |
1 |
1 |
1.5 |
2 |
2.5 |
2.5 |
3 |
