When an oil spills occurs, the ANTI-OVERTURNING OIL BOOM is used to cut off the oil spilled from the water surface and conduct diversion for the oil spill, so as to facilitate the recovery of oil spill. At the same time, in order to ensure that the oil boom cannot fall down in the torrent and has good wave riding performance, the turbulent flow reduction system is set at the apron to overcome the impact of water flow on the boom body and avoid the oil spill caused by overturning the oil boom. In addition to intercepting oil spills, it can also be used for cleaning garbage and other floating objects on the water surface and protecting specific water areas.
Parameter | WGV600T | WGV750T | WGV900T | WGV1000T | WGV1200T |
Overall Height of Connector(mm) | 590 | 750 | 900 | 1000 | 1200 |
Water Level(mm) | 150 | 300 | 350 | 380 | 450 |
Height below Water(mm) | 380 | 450 | 550 | 620 | 750 |
Length per Section(m) | 20 | 20 | 20 | 20 | 20 |
Max. Tensile Strength(KN) | ≥20 | ≥30 | ≥40 | ≥60 | ≥80 |
Max. Resistance to Wave Height(m) | ≥0.5 | ≥1 | ≥2 | ≥2.5 | ≥3 |
Max. Resistance to Wind Speed(m/s) | ≥6 | ≥6 | ≥8 | ≥10 | ≥12 |
Max. Resistance to Current Speed (Section) | ≥1 | ≥1.5 | ≥2.5 | ≥3.5 | ≥5 |
